M6-1.00 x 30 MM Non-Serrated Hex Flange Bolt, Full Thread / Class 10.9 Steel / Zinc / ISO 898-1 Class 10.9; DIN 6921
$362.70
Same-Day Shipping
Certified Specs
Volume Pricing
Product Description
M6-1.00 x 30 MM Non-Serrated Hex Flange Bolt, Full Thread / Class 10.9 Steel / Zinc / ISO 898-1 Class 10.9; DIN 6921
Specifications
| Material | Alloy Steel |
|---|---|
| Finish | Zinc |
| Grade | Class 10.9 |
| Size | M6-1.00 |
| Length | 30mm |
| Head Style | Hex Flange Head |
| Drive | External Hex |
| Thread Pitch | 1.00mm |
| Thread Class | Coarse |
| Point Type | Chamfered |
| Hardness | C32 - C39 |
| Tensile Strength | 145000 |
| Standard | DIN 6921 |
| Measurement System | Metric |
RoHS Compliant
Frequently Asked Questions
What does the metric class number mean?
The first number indicates tensile strength (e.g., 12 = 1,200 MPa). The second number is the yield-to-tensile ratio. So Class 12.9 has 1,220 MPa tensile strength and yield at 90% of tensile. Class 12.9 is equivalent to inch Grade 8.
.00 x 20 MM Flange Bolt Class 10.9 Steel Zinc CR+3 Full Thread
Family: VJ1
Select size and quantity, then add to cart
Loading filters...
|
Loading family products...
|
Technical Specifications
Thread Size
M6-1.00
Thread Type
Metric Coarse
Material
Alloy Steel
Grade
Class 10.9
Head Style
Hex Flange Head
Country of Origin
Japan
Thread Pitch
1.00mm
Tensile Strength
145000
Hardness
C32 - C39
SKU
VJ1030-1200
