5/16"-18 x 2 1/2" Type F Thread Cutting Screws / Phillips / Flat Head / 18-8 Stainless Steel / Passivated / Made in USA
- Stainless Steel
- 18-8
- Passivated
- 18 TPI · Coarse
- ASME B18.6.3
$135.74
$4.52 / pc
Package of 30
Volume pricing: the bulk box price per piece is shown above. Need more? Request a quote →
Net 30 terms for approved accounts. Apply for wholesale →
Product Description
5/16"-18 x 2 1/2" Type F Thread Cutting Screws / Phillips / Flat Head / 18-8 Stainless Steel / Passivated / Made in USA
5/16"-18 x 2 1/2" thread-cutting screw in 18-8 Stainless Steel, passivated finish. For cutting a clean mating thread in brittle or hard material.
- FLAT HEAD — an 82° countersunk head that sits flush with the surface
- PHILLIPS DRIVE — the familiar cross recess; it is designed to cam out under load, so ease off the clutch at depth
- PASSIVATED — an acid treatment that strips free iron from the stainless surface so it cannot bleed rust down the workpiece
- FULL THREAD — threaded to the head, so it grips over the whole length and suits thin or variable stack-ups
- 18-8 STAINLESS — the 300-series austenitic workhorse — non-magnetic, excellent general corrosion resistance, and it will not rust-stain the surface around it
🇺🇸 Made in USAStainless
Frequently Asked Questions
How corrosion-resistant is this stainless steel fastener?
Stainless steel fasteners resist rust and corrosion in most environments. For specific corrosion requirements, consult our engineering team or the appropriate ASTM specification.
$135.74
$4.52/pc
Type F Thread Cutting Screws / Phillips / Flat Head
Select size and quantity, then add to cart
Loading filters...
|
Loading family products...
|
5/16"-18 x 2 1/2" Type F Thread Cutting Screws / Phillips / Flat Head / 18-8 Stainless Steel / Passivated / Made in USA
SKU: 3140FPF188-30
Technical Specifications
Thread Size
5/16"-18
Thread Series
UNC
Thread Pitch
18 TPI
Thread Coverage
Full Thread
Thread Action
Thread Cutting
Tapping Type
Type F
Length
2 1/2"
Material
Stainless Steel
Grade
18-8
Finish
Passivated
Drive
Phillips
Head Style
Flat Head
Standard
ASME B18.6.3
Country of Origin
USA
Point Type
Blunt Tapered
Head Diameter (in)
0.556–0597
Measurement System
Inch
Head Height (in)
0.165–0.191
SKU
3140FPF188-30
