5/16"-18 x 2 1/2" Trilobe Thread Forming Screws for Metal / Unslotted / Hex Washer Head / Low Carbon Steel / Zinc
- Steel
- Zinc
- 18 TPI · Coarse
- ASME B18.6.3
$204.56
$3.41 / pc
Package of 60
Volume pricing: the bulk box price per piece is shown above. Need more? Request a quote →
Net 30 terms for approved accounts. Apply for wholesale →
Product Description
5/16"-18 x 2 1/2" Trilobe Thread Forming Screws for Metal / Unslotted / Hex Washer Head / Low Carbon Steel / Zinc
RoHS Compliant
$204.56
$3.41/pc
Trilobe Thread Forming Screws for Metal / Unslotted / Hex Washer Head
Family: RW
Select size and quantity, then add to cart
Loading filters...
|
Loading family products...
|
5/16"-18 x 2 1/2" Trilobe Thread Forming Screws for Metal / Unslotted / Hex Washer Head / Low Carbon Steel / Zinc
SKU: 3140RW-60
Technical Specifications
Thread Size
5/16"-18
Thread Series
UNC
Thread Pitch
18 TPI
Thread Coverage
Full Thread
Thread Action
Thread Forming
Tapping Type
Trilobular
Length
2 1/2"
Material
Steel
Finish
Zinc
Drive
External Hex
Head Style
Hex Washer Head
Standard
ASME B18.6.3
Country of Origin
Import
Head Diameter (in)
1/2
Measurement System
Inch
Head Height (in)
0.208–0.230
Width Across Flats
1/2"
SKU
3140RW-60
