1/4"-20 x 2 1/4" Trilobe Thread Forming Screws for Metal / Unslotted / Hex Washer Head / Low Carbon Steel / Zinc
- Steel
- Zinc
- 20 TPI · Coarse
- ASME B18.6.3
$118.20
$1.18 / pc
Package of 100
Volume pricing: the bulk box price per piece is shown above. Need more? Request a quote →
Net 30 terms for approved accounts. Apply for wholesale →
Product Description
1/4"-20 x 2 1/4" Trilobe Thread Forming Screws for Metal / Unslotted / Hex Washer Head / Low Carbon Steel / Zinc
RoHS Compliant
$118.20
$1.18/pc
Trilobe Thread Forming Screws for Metal / Unslotted / Hex Washer Head
Family: RW
Select size and quantity, then add to cart
Loading filters...
|
Loading family products...
|
1/4"-20 x 2 1/4" Trilobe Thread Forming Screws for Metal / Unslotted / Hex Washer Head / Low Carbon Steel / Zinc
SKU: 1436RW-100
Technical Specifications
Thread Size
1/4"-20
Thread Series
UNC
Thread Pitch
20 TPI
Thread Coverage
Full Thread
Thread Action
Thread Forming
Tapping Type
Trilobular
Length
2 1/4"
Material
Steel
Finish
Zinc
Drive
External Hex
Head Style
Hex Washer Head
Standard
ASME B18.6.3
Country of Origin
Import
Head Diameter (in)
3/8
Measurement System
Inch
Head Height (in)
0.172–0.190
Width Across Flats
3/8"
SKU
1436RW-100
