5/16"-12 x 3/4" Type AB Self-Tapping Screws / Unslotted / Indented Hex Washer Head / Steel / Zinc CR+3
$9.99
Same-Day Shipping
Certified Specs
Volume Pricing
Product Description
5/16"-12 x 3/4" Type AB Self-Tapping Screws / Unslotted / Indented Hex Washer Head / Steel / Zinc CR+3
Specifications
| Material | Steel |
|---|---|
| Finish | Zinc |
| Size | 5/16"-12 |
| Head Style | Hex Washer Head |
| Drive | No Drive (Unslotted) |
| Thread Pitch | 12 TPI |
| Point Type | Type AB |
| Standard | ASME B18.6.4 |
| RoHS Compliance | RoHS Compliant |
| Measurement System | Inch |
RoHS Compliant
Frequently Asked Questions
What pilot hole size do I need for this self-tapping screw?
The pilot hole should be approximately 70-80% of the screw outside diameter. For #6 screws use .128" drill (#30). For #8 use .157" (#21). For #10 use .180" (#15). For 1/4" use .228" (#1). Always test in scrap material first to verify proper engagement.
Flat Head Phillips Type AB Tapping Screw - Zinc
Family: 697
Select size and quantity, then add to cart
Loading filters...
|
Loading family products...
|
Technical Specifications
Thread Size
5/16"-12
Thread Type
Coarse
Material
Steel
Head Style
Hex Washer Head
Country of Origin
Import
Thread Pitch
12 TPI
SKU
697799-1000
