M20-2.50 x 65mm Socket Head Cap Screws, Full Thread / Class 12.9 Steel / Zinc CR+6
- Steel
- Class 12.9
- Zinc
- 2.50mm · Coarse
- ISO 898-1
$455.29
$18.21 / pc
Package of 25
Volume pricing: the bulk box price per piece is shown above. Need more? Request a quote →
Net 30 terms for approved accounts. Apply for wholesale →
Product Description
M20-2.50 x 65mm Socket Head Cap Screws, Full Thread / Class 12.9 Steel / Zinc CR+6
Frequently Asked Questions
What does the metric class number mean?
The first number indicates tensile strength (e.g., 12 = 1,200 MPa). The second number is the yield-to-tensile ratio. So Class 12.9 has 1,220 MPa tensile strength and yield at 90% of tensile. Class 12.9 is equivalent to inch Grade 8.
What hex key size do I need for this socket head cap screw?
For this M20-2.50 Socket Head Cap Screw, use a 17 mm hex key (Allen wrench).
$455.29
$18.21/pc
.50 x 5mm Socket Head Cap Screw, Full Thread / Class 12.9 Alloy Steel / Zinc Bake
Family: 841
Select size and quantity, then add to cart
Loading filters...
|
Loading family products...
|
Technical Specifications
Thread Size
M20-2.50
Length
65mm
Thread Type
Coarse
Material
Steel
Grade
Class 12.9
Finish
Zinc
Drive
Hex Socket (Allen)
Head Style
Socket Head
Standard
ISO 898-1
Thread Pitch
2.50mm
Thread Class
Coarse
Tensile Strength
174000
Hardness
C39 - C44
RoHS Compliance
Non-Compliant
Measurement System
Metric
SKU
841296-25
