#10-12 x 1" Type A Self-Tapping Screws / Slotted / Pan Head / Steel / Zinc / ASME B18.6.4
$125.74
Same-Day Shipping
Certified Specs
Volume Pricing
Product Description
#10-12 x 1" Type A Self-Tapping Screws / Slotted / Pan Head / Steel / Zinc / ASME B18.6.4
Specifications
| Material | Steel |
|---|---|
| Finish | Zinc |
| Size | #10-12 |
| Length | 1" |
| Head Style | Pan Head |
| Drive | Slotted |
| Thread Pitch | 12 TPI |
| Point Type | Type A |
| Standard | ASME B18.6.4 |
| RoHS Compliance | RoHS Compliant |
| Measurement System | Inch |
RoHS Compliant
Frequently Asked Questions
What pilot hole size do I need for this self-tapping screw?
The pilot hole should be approximately 70-80% of the screw outside diameter. For #6 screws use .128" drill (#30). For #8 use .157" (#21). For #10 use .180" (#15). For 1/4" use .228" (#1). Always test in scrap material first to verify proper engagement.
Flat Head Self-Tapping Screw, Type A / Steel / Zinc
Family: 696
Select size and quantity, then add to cart
Loading filters...
|
Loading family products...
|
Technical Specifications
Thread Size
#10-12
Material
Steel
Head Style
Pan Head
Thread Pitch
12 TPI
SKU
696473-3500
