Self-Tapping vs Self-Drilling vs Thread-Forming Screws: The Complete Guide

Even experienced engineers get confused by these terms. The fastener industry uses "self-tapping" and "self-drilling" almost interchangeably, and "thread-forming" gets thrown around without clear definitions. Let us clear this up once and for all.

The Quick Answer

• Self-Drilling = Has a drill-bit point, makes its own hole, NO pilot hole needed
• Self-Tapping = Umbrella term for screws that create their own threads (includes thread-forming AND thread-cutting)
• Thread-Forming = A type of self-tapping that displaces material (no chips)
• Thread-Cutting = A type of self-tapping that cuts material (creates chips)

Self-Drilling Screws (TEK Screws)

Self-drilling screws have an actual drill-bit point that bores its own hole through the material. No pilot hole required — the screw does all the work.

Key Characteristics:

• Drill-bit tip that penetrates material
• Primarily for metal-to-metal applications
• Also called TEK screws or drill-point screws
• Saves time by eliminating the pre-drilling step

Point Types (Drill Capacity):

Higher point numbers = longer drill flute = thicker material capacity

Self-Tapping Screws (The Umbrella Term)

Here is where the confusion starts. Self-tapping is a broad category that includes any screw that creates its own mating threads. This includes both thread-forming and thread-cutting screws.

Unlike self-drilling screws, self-tapping screws require a pilot hole — they tap the threads, but they do not drill the initial hole.

Thread-Forming Screws

Thread-forming screws displace material to create threads without removing any metal. Think of it like pushing material aside rather than cutting it away.

Best for: Sheet metal, soft metals, plastics, plywood

Common Point Types:

• Type A — Coarse threads, gimlet point, for sheet metal up to 0.050\"
• Type AB — Finer threads than Type A, gimlet point, for sheet metal and resinous plywood
• Type B — Finer pitch, blunt point, for sheet metal 0.050\" and thicker
• Type C — Machine screw thread pitch, blunt point, for applications requiring interchangeability with machine screws

Thread-Cutting Screws

Thread-cutting screws have cutting edges that remove material, creating chips as they form threads. They work like a tap.

Best for: Harder materials, castings, brittle plastics, die castings

Common Point Types:

• Type 1 — Blunt point with tapered threads and cutting slot
• Type 17 — Similar to Type 1 but with a longer point for wood applications
• Type 23 — Machine screw thread, for plastics and metals
• Type 25 — Coarse thread for brittle plastics and die castings
• Type F — Machine screw thread, multi-cutting edge, for heavy-gauge sheet metal
• Type T — Similar to Type 23, for plastics
• Type BF — Combines Type B body with Type F cutting threads
• Type BT — Combines Type B body with Type T cutting threads

How to Choose the Right Screw

Choose Self-Drilling (TEK) When:

• You are fastening metal to metal
• You want to eliminate pre-drilling
• Speed and efficiency are priorities
• Material thickness matches the point type capacity

Choose Thread-Forming When:

• Working with sheet metal, plastics, or soft materials
• You can pre-drill a pilot hole
• You need strong thread engagement
• Chips and debris are a concern

Choose Thread-Cutting When:

• Material is too hard for thread-forming
• Working with castings or brittle materials
• You need precise thread fit
• The material cannot tolerate deformation

Quick Reference Chart
